How to Effectively Reduce Losses in Inductor Components?

2025.5.8 Articles GOTREND

串聯與並聯的基本概念




1、How to Effectively Reduce Losses in Inductor Components?

In circuit design, the losses of inductor components directly impact system efficiency andstability. So, what are the main sources of inductor losses, and how can they be effectivelyreduced ? Inductor losses are primarily categorized into copper loss and core loss, which are influenced byfactors such as conductor resistance, magnetic core material properties, and operatingconditions (e.g., frequency, temperature). To minimize these losses, optimizations can be madein material selection, structural design, and thermal management. The following sections willexplore the causes of these losses and specific methods for reducing them.


2、 Causes and Reduction Methods for Copper Losses

 Causes : Copper loss mainly results from DC resistance (DCR) of the conductor andhigh-frequency effects, including skin effect and proximity effect.
 Reduction Methods:
1. Use low-resistivity conductors: High-purity copper wire or silver-plated copper wire canhelp reduce DC resistance.
2. Adopt Litz wire: Litz wire, composed of multiple twisted fine strands, effectively mitigatesskin and proximity effects, making it suitable for high-frequency applications.
3. Optimize winding structure: Implementing segmented winding or interlayer insulationdesigns can help reduce the impact of the proximity effect.
4. Increase conductor cross-sectional area: When space allows, using thicker conductors canhelp lower resistance.



3、 Causes and Reduction Methods for Core Loss

Causes : Core loss consists of hysteresis loss and eddy current loss, which are closely related to theproperties of the magnetic core material, operating frequency, and flux density.
Reduction Methods:
1. Use low-loss magnetic core materials: Materials such as high-frequency ferrite ornanocrystalline alloy have a smaller hysteresis loop area and higher resistivity,significantly reducing core loss.
2. Control operating frequency and flux density: Selecting an appropriate frequency rangebased on application requirements helps prevent core saturation, while reducing fluxdensity can significantly lower core loss.
3. Implement distributed air gap design: Introducing distributed air gaps in the corereduces localized flux density and minimizes hysteresis loss.
4. Use laminated core structures: Layering and insulating the core can effectively suppresseddy current loss.



4、 Environmental and Thermal Management Optimization

Causes : Increased temperature leads to higher conductor resistance and degradedmagnetic core performance, exacerbating overall losses.
Reduction Methods:
1. Improve heat dissipation design: Using an open-core structure or adding heatsinks can enhance thermal conduction efficiency.
2. Use high-temperature-resistant materials: Selecting magnetic cores and insulationmaterials that can withstand high temperatures ensures stable operation inextreme conditions.
3. Control operating temperature: Implementing air cooling, liquid cooling, orthermal management circuits helps maintain inductor temperature within a saferange.


5、 Additional Losses in High-Frequency Applications and Solutions

Causes : At high frequencies, the parasitic capacitance (Cparasitic) of the inductor canlead to resonant losses, degrading overall component performance.
Reduction Methods:
1. Optimize winding techniques: Using single-layer or spaced winding helps reduceparasitic capacitance.
2. Select low-dielectric constant bobbin materials: Materials such as ceramics orspecialized plastics can minimize parasitic capacitance effects.
3. Control the self-resonant frequency (SRF) : Ensuring that the operating frequencyremains well below the SRF during design helps avoid resonant losses.


6、 Conclusion

GOTREND Technology has provided a comprehensive overview of inductor losses. Sinceinductor losses are closely related to the properties of the magnetic core material—and there isa wide variety of core types, each with its unique characteristics—no direct comparison of lossmagnitude has been made. For example, commonly used ferrite is not a single material butconsists of multiple subtypes, just as powdered iron cores and other core materials come innumerous variations. Therefore, to accurately compare the losses of different magnetic cores,an in-depth analysis must be conducted based on the specific material and type.
For further discussions, feel free to contact GOTREND Technology for technical exchanges.
